Hi-Lift Jack Hi-Lift All-Cast Jack – 60 in.

These Hi-Lift Jack Company Patriot Edition Jacks are sure to show your American Pride. They are finished off in good ol American red white and blue. The jacks have an adjustable top clamp clevis that allows them to be used for clamping, lifting, winching, or hoisting. With a base plate of 28 sq. in. and a super-strong upright cast steel bar, the jacks are tough enough to handle any situation. They feature easy, automatic operation for raising and lowering loads, and a speedy disengagement system that lets the lifting unit drop away when pressure is removed. The jacks use horizontal operating climbing pins for safe, positive contact.

• Hi-Lift All-Cast Jack
,
• Size: 60 in.
,
• Minimum Lift Height: 4.5 in.
,
• Maximum Lift Height: 49.75 in.
,
• Rated Load (RL): 4,660 lbs.
,
• RL on Upper 12 in.: 2,660 lbs.
,
• Tested Load (TL): 7,000 lbs.
,
• TL on Upper 12 in.: 4,000 lbs.
,
• Winching Capacity: 5,000 lbs.
,
• Clamping Capacity: 750 lbs.
,
• Overall Dimensions: 5 in. W x 9.63 in. D x 61.75 in. H
,
• Steel Handle: 30 in. Long x 1-5/16 in. Diameter
,
• Lifting Nose: 4.5 in. Long
,
• Base Plate: 28 sq. in.
,
• Weight: 31.31 lbs.
,
• Lifts, Winches, Clamps, & More
,
• All-Cast Construction for Superior Strength & Longevity
,
• Tested & Certified to Meet Applicable Requirements of ASME B30.1-2015
